REVOLUTION ELASTIC COUPLINGS


"REVOLUTION" series NORTHON flexible joints are used for connecting coaxial shafts and offer great advanteges, such as:
- little space occupied yet transmit very high torque
- near-perfect dynamic balancing
- low inertia moment so a high number of revs possible
- anti-oxidising with regard to external atmospheric agents since they are made of aluminium alloy
- easy dismantling and replacement of the flexible elements without having to move the connected machines
- possibility of having the hubs at the desired length
- greater angular and axial offsets
- possibility of having the flexible elements in different materials and hardness.

CONSTRUCTION FEATURES

- Hubs and sleeves in extruded aluminium and hardened
- Rubber elements in oil-resistant synthetic rubber NBR 70 shoreA
- Operating temperature from -30°C to +120°C
- On request be possible to have rubber elements with higher resistance
- Low moment of inertia and therefore greater speed

Fitting
Components
Safety regulations




REVOLUTION TYPE RE SERIES

Elastic couplings in aluminum, standard version

Data sheet

REVOLUTION TYPE REP SERIES

Elastic couplings in aluminum, version with one extended hub

Data sheet



REVOLUTION TYPE RE2P SERIES

Elastic couplings in aluminum, version with two extended hubs

Data sheet

TYPE REAF SERIES

Elastic couplings in aluminum, version with floating shaft

Data sheet
